Operation
High Speed Doors
Product Description
Principle
The UltraSecure 3000 is a vertically opening high-speed rolling metal door primarily for external use.
The door panel is made of aluminum slats connected to a special belt. The slats wind on up to three
variable sized disc modules. They do not stack or wind onto each other, which protects the slats
from excessive wear and produces smooth, contact-free frictionless operation that allows for the
high opening speed.
Absorbing profiles attached to the perimeter of the discs enables quiet operation and dampen vibra-
tion of the slats during winding.
The flat belt functions as a pulling device. Hinges and rollers are not necessary in this door system,
allowing for longer maintenance intervals and increased door life. Rubber connections between each
slat prevent moisture from entering and from settling between the slats.
The pulling power is transferred equally to the disc modules by a gear motor via a drive shaft. This is
also supported by tensioned springs located within the side columns. The door closes with assis-
tance from the weight of the panel.
The panel moves vertically within special guide rails located in the side frames.
The door may be opened manually in the event of a power outage by releasing the brake via the
side column mounted egress lever.
The UltraSecure 3000 is equipped with a wireless electric reversing edge and inline safety light cur-
tain photo eyes..
Slats
The slats of the Rapid Roll 3000 are double walled extruded anodized aluminum with rubber seals in
between. Each slat is individually connected and can be easily removed and replaced.
Window slats are available as an option.
Side Frame
The side frames and cross sections of the Rapid Roll 3000 are galvanized steel.
The various elements of the side frames come pre-assembled from the manufacturer.
During installation, the side frames must first be set up and fastened to the wall / floor in the upper
and lower area. The upper width gauge can help define the exact distance of the side frames.
After the side frames have been secured to the wall, the pre-assembled top roll with the rolled-up
door panel must be placed onto the top of the side frames and secured.
