SETTING SYSTEM OPTIONS
1) Press and hold until ―LIMIT SETUP‖ is shown on the display; Press
2) Press until ―SYSTEM OPTIONS‖ is shown; Press
Use and/or to cycle through the available options; Press to edit that
option.
Use and/or to change the value; Press to store that value
3) When finished—press until ―DOOR READY‖ is displayed
The Open and Partial Limits are all relative to the Closed Limit. If
the Closed Limit is reset to a different position, all other limit set-
tings will change relative to the new Closed Limit setting.
SETTING TIMERS
1) Press and hold until ―LIMIT SETUP‖ is shown on the display; Press
2) Press until ―SET TIMERS‖ is shown; Press
Use and/or to cycle through the available options; Press to edit an
option.
Use and/or to change the value; Press to store that value
3) When finished—press until ―DOOR READY‖ is displayed
