Technical data

17 Manual #001451 Version 4.2
Line One (1) Text
Line Two (2) Text
Startup:
R-Bac Industries
Door Not Ready
Normal Operation:
Door ready
Opening:
Opening — Full
Opening — Part
Open: Delay Timer Active
Auto1 Close Delay
Auto2 Close Delay
Man1 Close Delay
Man2 Close Delay
DTC Timer
Open Commanded :Delay Timer Active:
DTO Timer (Display shown during a
count - down of the timer.)
Closing:
Closing
Normal: Warning
Door Ready
Startup:
Version n.m
Normal Operation:
0000000 The zeros indicate the number of door
operations. The counter will advance with each
full or partial door opening. Version n.m (shown
until first cycle)
Opening:
Auto 1
Auto 2
Man 1
Man 2
Open Pb
Open On Panel
Photo 1 (Front)
Photo 2 (Rear)
Reversing Edge
Breakaway
Open: Delay Timer Active:
(Preventer, if any)
Open Commanded :Delay Timer Active:
Closing:
Auto 1
Auto 2
Man 1
Man 2
Close Pb
Close on Panel
Normal: Warning
Encoder Low Battery
Module D Loop Open
Module D Loop Short
Module D Loop Error
Module D Loop1 Open
Module D Loop1 Short
Module D Loop1 Error
Module D Loop2 Open
Module D Loop2 Short
Module D Loop2 Error
RevEdge Was Tripped
