Technical data

9 Manual #001451 Version 4.2
Before checking the following mentioned components the cover in front of the
spring housing and eventually the existing top roll and motor cover must be
dismantled.
Annually or 100,000 cycles.
Check retainer of the torque support and buffer. Annually or 100,000 cycles.
Check function of brake release lever. Annually or 100,000 cycles.
Check self-opening/manual opening/egress
Annually or 100,000 cycles.
Check flange bearing retainers of drive shaft. Annually or 100,000 cycles.
Check retainer of the spiral disk on the shaft. Annually or 100,000 cycles.
Check condition of sound isolation or black dampener profiles on the spiral disks. Annually or 100,000 cycles.
Exchange of flat lifting belts.
500,000 cycles.
Check surface of lamellas/slats for grinding and signs of damages. Annually or 100,000 cycles.
Check exact position of lamella sealing. Annually or 100,000 cycles.
Check fixing of lamellas on pulling device. Annually or 100,000 cycles.
Check solid position of lamella adapter/endplates.
Annually or 100,000 cycles.
Check for wear and tear on guidingrails, especially in the area of funnel (<4MM)
Annually or 100,000 cycles.
Check fixing and condition of the profiles as well as fixing at the wall Annually or 100,000 cycles.
Check condition and fixing of trailing chain for cable if equipped Annually or 100,000 cycles.
Check condition and installation of springs and spring fixing. Annually or 100,000 cycles.
Check leaf tensioning system if equipped. Annually or 100,000 cycles.
Exchange rubber cable/bungee cord if equipped 500,000 cycles.
Clean optic of photocells.
As necessary.
Exchange springs H<3m. 500,000 cycles.
Exchange springs H>=3m. 250,000 cycles.
Check condition and fixing of the spring belts. Annually or 100,000 cycles.
Lubrication of roller chain (only RR3000R).
Annually or 100,000 cycles.
Check completeness of wiring diagram. Annually
Check main switch/CEE-plug and control box lock. Annually
Check fixing of control panel Annually
Check function of staionary and/or pre-runing photocells Every 6 months or 25,000 cycles
Verify stopping position of limits Annually or 50,000 cycles.
Check function of electric reversing edge if equipped Every 6 months or 25,000 cycles
Door leaf
Guiding rails
Side columns and lintel profile
Counter balance system
Control Box and additional components (like safeties & actuators)
Inspection Plan
Installation fixings
Drive unit
Drive shaft
Observe the safety notices within the operation manual. Power to the door must be shut off prior to
inspection of any door component.
