User Manual

Original instructions for use
467 776_a 13
ORIGINAL INSTRUCTIONS FOR USE
Contents
About this handbook........................................ 13
Product description.......................................... 13
Scope of delivery............................................. 14
Safety instructions............................................14
Assembly..........................................................15
Startup..............................................................15
Maintenance and care..................................... 16
Storage.............................................................17
Disposal............................................................17
Help in case of a malfunction.......................... 17
LED displays.................................................... 18
Warranty........................................................... 19
EU declaration of conformity............................20
ABOUT THIS HANDBOOK
Read this documentation before starting up
the machine. This is a precondition for safe
working and flawless operation.
Observe the safety warnings in this docu-
mentation and on the product.
This documentation is a permanent integral
part of the product described and must be
passed on to the new owner if the product is
sold.
Explanation of symbols
CAUTION!
Following these safety warnings care-
fully can prevent personal injury and/or
material damage.
ADVICE
Special instructions for greater ease of
understanding and improved handling.
PRODUCT DESCRIPTION
This documentation describes several different
models of house water systems. Identify your mo-
del using the identification plate.
Product overview
(Fig. A - E)
1 Clear filter cover
2 Pump housing
3 Filling screw
4 Pump outlet/pressure line connection
5 Motor housing
6 Storage vessel
7 Screw-on point
8 Pressure gauge
9 Drain screw pump chamber
10 Drain screws filter chamber
11 Pump inlet/suction line connection
12 Water cock
13 Pressure line
14 Angle nipple
15 Seal
16 Connection nipple
17 Seal
18 Suction line
19 Filter spanner
20 Filter seal
21 Filter
22 Check valve
23 Seal non-return valve
24 Housing seal
25 Screw-in nipple
26 Seal
27 Measuring unit float body
28 Valve closing cover
29 Valve
Inox stainless steel
Units marked with the designation "INOX" are
supplied in stainless steel. The structure and func-
tion are unaffected by this.
