User manual

Specifications
akYtec GmbH · Vahrenwalder Str. 269 A · 30179 Hannover· Germany · Tel.: [phone] · www.akytec.de
4
3 Specifications
ITP11 can be ordered in different versions. They differ in the display color.
Ordering key:
Table 1
Supply current
from current loop
Input signal
4-20 mA (2-wire)
Inputs
1
Measuring range
3.8…22.5 mA
Normal operation
3.2…25 mA
Voltage drop, max.
10 V
Accuracy
0.2% + 1 digit
Display
LED, 7-segment display
Character height
14 mm
Display colour
red or green
Number of digits in display
4
Sampling rate (without damping)
1 reading / s
IP Code
front IP65, rear IP20
Dimensions
48 x 26 x 65 mm
Weight
approx. 30 g
Protection class
III
Ambient temperature
-30…+70 °C
Storage temperature
-40…+80 °C
Humidity
up to 80% (non-condensing)
ITP11-X
- - Display color red
G - Display color green
