142MM

210MM

Read this manual before use

ESS-209 USER MANUAL

General Function Description

FM radio Function

Bluetooth Connection

Light Functional Description

FM Function Description

MP3 Function Description

43 5

1. : Short press is previous song/FM channel ; hold the tracking previous key is

volume down.

2. :Short press is next song/FM channel; hold the tracking next key is volume up.

3. Light / Mode:Short press is switch to the mode : Aux In→USB\TF→FM →BT ; hold is

switch the light effects , double click is control the light On/ Off.

4. /PAIR /TWS : Short press is Play / Pause; In Bluetooth status , hold press 5 seconds to

re-enter the pairing status.; Hold press more than 0.5 seconds to enter TWS status , In FM

Status ,Hold to automatic searching radio, Press to mute in FM and Aux .

USB/TF Function Description

Panel Function

3 4

5 6 7 8 9 10 11

USB

OFF/ON

USB5V

MIC

AUX

1. Light / Mode

2. Track Previous / Volume Down

3. Play / Pause / Scan / TWS/PAIR

4. Track Next / Volume Up

5. TF Card Slot

6. USB slot

7. Power ON/OFF

8. DC 5V Charging Port(USB 5V)

9. Mic Input

10. AUX IN Port

11. Charge Indicator

/SCAN/TWS

1.U-Disk: Playing the stocked music automatically when USB was inserted

2.TF Card: Playing the stocked music automatically when TF card was inserted.

3.Play/Pause Break：Short press to play / pause.

4. Track Previous / Next Key：Short press for previous/next song.

1.Short press the mode button to switch FM status.

2.PLAY/PAUSE break : Long press to automatic searching radio, short press to mute and

mute canceled function.

3.Previous/Next Song Key: Short press for upwards or downwards to the searched

broadcasting station.

4.Note:Please automatic searching radio when first use.Attach USB or AUX cable

to enhance FM reception.

Microphone Function Description

1. You can use the mic once insert it.

It is suggested to pause and mute the music before using mic.

Bluetooth Function Description

1.Enter the Bluetooth waiting for pairing status automatically

when under the Bluetooth mode. Use your Bluetooth device search model for

"MPD659" for pairing, you will hear a sound once paired successfully.

2.Music playing: short press Play/Pause and Previous/Next Song Key to control Bluetooth

player.

3.Manual Bluetooth pairing : In the Bluetooth status has been connected, hold the

play / pause button 5s to re-enter the pairing status.

TWS Function Description

1.Please purchase 2 MPD659 Bluetooth speaker if you want to use TWS function. Turn

on one speaker, connect the speaker via Bluetooth to your device.You should see

‘’MPD659” in the list over Bluetooth devices.

2.Turn on the second speaker, then hold press more than 0.5 seconds with the TWS

marking of first speaker. You will hear a “beep”sound, the devices are connected in TWS

mode. You can now enjoy True Wireless Stereo (TWS)* for Stereo Audio Experi-

ence.When playing music, the first speaker is the left channel and the second speaker is

the right channel.

3.To disconnect the speaker from TWS, hold press more than 0.5 seconds of TWS

button on the first speaker.

You will hear a “beep” sound, the devices are disconnected from TWS mode.

To connect TWS again repeat the steps above.

Noted: TWS mean True Wireless Stereo.You can enjoy a stereo BT music system when

you have two of speakers.

Packing List

Unit Speaker..............................................1

User Manual..............................................1

Wired Microphone.............................1

USB cable.....................................................1

Caution

•The AC / DC adaptor and main unit shall not be exposed to dripping or splashing

and that no objects filled with liquids, such as vases shall be placed on the apparatus

and AC / DC adaptor.

•Minimum distances 20-30 cm around the apparatus for sufficient ventilation.

•The ventilation should not be impeded by covering the ventilation openings with items,

such as newspaper , table , cloths , curtains ,etc.

•No naked flame sources , such as lighted candles , should be placed on the appara-

tus.

•When the mains plug of AC / DC adaptor is used as the disconnect device, the

disconnect device shall remain readily operable.

•To be completely disconnected the power input the AC / DC adaptor shall be discon-

nected

from the mains completely.

•The AC /DC adaptor should not be obstructed or should be easily accessed during

intended use.

•The use of apparatus in tropical climate.

•The marking information is located at the bottom of apparatus .

MP3 Function Description

Charging Indication Description

1.when in the low power state that requires charging，Product volume will automatically

fall to about 70% of the main volume.

2.Use DC 5V adaptor for charging , the charging indicator light on,the product is being

charged, after fully charging,indicator goes out .

Note: For the first time, charge it more than 12 hours, if the unit is not used for a long

time ; Otherwise it will cause damage to the battery.

MP3 Function Description

Specifications

Power source: DC 5V 1

FM Frequency: 90-20MHz

Output power: 5W ( RMS )

Rsponse Frequency:90Hz-20KHz

Speaker size:6.5"3Ω*1

Light Functional Description

S/N:≥60dB

Note :Specifications are subject to change for continuous improvement without prior

notice.

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modiﬁcations to this device not explicitly approved by

manufacturer could void your authority to operate this equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

RF Exposure Information

The device has been evaluated to meet general RF exposure requirement. The device

can be used in portable exposure condition without restriction.
