USER MANUAL 10.1” Touch Panel PC PMW10ID3S-H1-4RT Rev 1.
American Industrial Systems, Inc. http://www.aispro.com Quick solution for: • Building automation • Access control • Room Information Display User Guide 10.
Table of Contents Copyright: .........................................................................................................................................................6 FCC rules: ..........................................................................................................................................................6 Important Recycle Instruction: .........................................................................................................................
160GB Hard Disk Drive............................................................................................................................12 Dimensions .............................................................................................................................................12 Environmental Requirements.................................................................................................................12 General............................................................
Mounting the Panel PC ...............................................................................................................................16 Panel mount hardware ...........................................................................................................................17 Dimensions .............................................................................................................................................17 Make a rectangle hole to match the panel dimensions. .....
Copyright: The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright © 2013 American Industrial Systems. All rights are reserved. No part of this document may be reproduced, translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
Usage Notice ! Warning! To prevent the risk of fire or shock hazards, do not expose this product to rain or moisture. Do not open or disassemble the product as this may cause electrical shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. Do: • • • • Turn off the product before cleaning.
Introduction Applications: Quick solution for: • Building automation • Access control • Room Information Display About PMW10ID3S-H1-4RT PM = Panel Mount W = Wide width ratio of 16:10 10 = 10.
Back Panel I/O Port 1 x Power Switch 2 x RJ-45 (LAN) 1 x RS-232 only 2 x USB 2.0 1 x VGA 1 x RS-232/422/485 (configurable) 1 x Terminal Block (Phoenix Type) Bottom side Power Switch AC power switch Ethernet interface The Motherboard is equipped with Broadcom BCM57780 chipset which is fully compliant with the PCI 10/100/1000 Mbps Ethernet protocol compatible. It is supported by major network operating systems. The Ethernet ports provide two standard RJ-45 jacks.
Serial COM port COM1 port supports RS232. COM2 port supports RS232/422/485, factory jumper setting is to RS232. USB ports 2 x USB 2.0 ports support hot plug-in connection.
Mother Board Product Overview The panel PC is integrated with Intel® NM10 express chipset and Atom D2550 Processor. The Intel Atom Processor with 32nm low power design enables down to 50% less average power consumption and the chipset delivers up to 4x improvement in graphics performance and enables up to 50% higher data transfer bus speed rate.
Main Memory 2GB DDR3 800/1066 MHz, up to 4GB Chipset Intel® NM10 express chipset Storage Device 160GB Hard Disk Drive Dimensions ~286 x 182 x 50mm (also see: Product Mechanical Drawings) Environmental Requirements Temperature - Operating: 0°C to 45°C (32°F to 113°F) Temperature - Storage: -20°C to 60°C (-4°F to 140°F) Humidity (Non-condensing) - 30 to 90% RH @ 40° C Vibration Protection - 5 to 500 Hz, 1 Grms random vibration General Input Power 12 Terminal Block (Phoenix Type) Approvals Designed for C
Native (Optimal) Resolution 1024 x 600 WSVGA Number of Colors 262K Brightness (Typical) LCD Panel: 200 nits PCT Touch: 160 nits Contrast Ratio 500:1 Touch Screen Transmittance 80 % Hardness 3H (JIS-K5600-5-4) Viewing Angle Horizontal: 140° Total Vertical: 120° Total Touch Technology Analog Resistive 4 wire Features and Benefits ▪ Portfolio of widescreen Window-based PCs for operator monitoring and control ▪ Flexible, reliable, and ruggedized for open platform HMI/SCADA ▪ All steel construction for h
Package Content Driver CD for touch screen and other features Recovery CD for restoring back to factory condition Paper back recovery manual PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 14
12 VDC Power supply Minimum power requirement is 24 watts Standard AC Power cord American 3 Prong Phoenix to power supply prewired This connector has adhesive as a strain relief. Wire for screw connectors This is used when installed in an environment that already has 12 volts available. A second phoenix connector is supplied without adhesive.
Product Dimension PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 16
Mounting the Panel PC Panel mount hardware Dimensions PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 17
Make a rectangle hole to match the panel dimensions. To use the mounting clips, panel must not exceed 12 mm.
PMW10ID3S-H1-4RT User Guide - American Industrial Systems Page 19
