User's Manual

Cabling
23
Connecting EasyST to Power
EasyST is powered by an AC/DC power supply adapter which supplies the EasyST with 6 VDC (7
Watts). The AC/DC adapter is simply plugged into a standard electrical wall outlet (110/240 VAC;
50/60 Hz). The power adapter provides interchangeable prongs
(e.g. American vs. European) that
can be replaced to suit country electrical standards in which the EasyST is being installed.
Note: Any AC/DC power adapter which is Class 2, LPS, and safety approved according to
national rules and that provides rated input of 100-240 V, 50/60 Hz, 0.4 A and output of 6 V,
2 A DC, may be used for powering the EasyST.
Changing the AC/DC Power Adapter's Prongs
The AC/DC power adapter provides interchangeable prongs to suit electrical wall outlet sockets
in the country in which the EasyST is being installed.
To change the plug prongs:
1. Remove the prongs by forcibly sliding the prongs upwards, away from the power cord.
2. Align the desired prongs with the adapter's prong groove, and then slide the prongs onto
the adapter in the orientation as shown in the figure below. Ensure that the prongs reach
the end of the prong groove.
