Maximum Output TX Power
Table 1 - SSRM FCC Maximum Output TX Power
Frequency
Band
FCC
TX EIRP
Antenna Gain
2.3 GHz
26dBm
42dBm
16dBi
2.5GHz
26.94dBm
44.44dBm
17.5dBI
Table 2 - SSRM ETSI Maximum Output TX Power
Frequency
Band
ETSI
TX EIRP
Rest of the World
TX EIRP
Antenna Gain
2.3 GHz
26dBm
42dBm
26dBm
42dBm
16dBi
2.5GHz
26.94dBm
44.44dBm
26.94dBm
44.44dBm
17.5dBI
Caution: Do not set maximum output TX power to higher than local regulations.
Antenna Types
Table 3 - 2.x GHz Antenna Types - Technical
Type
Frequency range
Gain
Part number
Directional Dual-Polarized Panel
2.3-2.36 GHz
16 dBi
07-1160-01
Directional Dual-Polarized Panel
2.5-2.7 GHz
17.5 dBi
07-1160-01
SSRM Antenna Usage
SSRM has two (2) RF ports that can be connected to two single-port antennas
Note: Appropriate mounting kit (included) for the antenna(s) is required.
 Dual polarized antenna with two (2) ports - connected via 2 RF jumper cables.
The following table describes the antenna arrays:
Table 4 - Antenna arrays
Frequency
Band
# of
Receivers
Sector
Antenna Type
# of Antennas
2.3 GHz
2
45º
2.3-2.36 GHz Dual Polar
Antenna - mounting included
1
2.5 – 2.7 GHz
2
45º
2.5-2.7 GHz Dual Polar
Antenna - mounting included
1
