EasyST Hardware Installation User Guide
Page 14 Commercial in Confidence UWB-D00128 Rev K
2.1 EasyST Frequency Ranges
The table below lists the frequency range of EasyST models currently available. This table will
grow as more models become available.
Table 2 - EasyST Frequency Ranges
Frequency Band Channel Bandwidth
698 – 748 in MHz TDD mode ¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
1.39 – 1.524 in GHz TDD mode ¾ 1.5 MHz
¾ 1.75 MHz
¾ 2.5 MHz
¾ 5 MHz
2.5 – 2.69 GHz in TDD mode
NPI
¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
2.7 – 2.9 GHz in TDD mode
NPI
¾ 3 MHz
¾ 6 MHz
¾ 10 MHz
3.3 – 3.5 GHz in TDD mode ¾ 1.75 MHz
¾ 2.75 MHz
¾ 3.5 MHz
¾ 5 MHz
3.4 – 3.6 GHz in FDD mode ¾ 1.75 MHz
¾ 3.5 MHz
3.6 – 3.8 GHz in TDD mode ¾ 1.75 MHz
¾ 3.5 MHz
¾ 5 MHz
4.9 – 5.0 GHz in TDD mode ¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
5.47 – 5.725 GHz in TDD mode ¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
5.725 – 5.875 GHz in TDD mode ¾ 2.5 MHz
¾ 5 MHz
¾ 10 MHz
