User's Manual
Table Of Contents
- Hardware Installation Guide
- Contents
- About this Guide
- 1. Overview
- 2. Safety Guidelines
- 3. Package Contents
- 4. Required Tools
- 5. Radio Site Planning
- Part I: Base Station Installation
- Part II: CPE Installation - Subscriber Premises Radio (SPR)
- Part III: CPE Installation - Indoor Data Radio Indoor (IDR)
- A. Glossary
- B. Installing the BSPS
- B.1. Basic Design
- B.2. Physical Dimensions
- B.3. Electrical Site Requirements
- B.4. BSPS Cabinet Cabling
- B.5. Installation Summary
- B.6. BSPS Batteries
- B.7. Rectifiers
- B.8. Operating the System Controller
- B.9. Powering on BSPS
- B.10. Connecting BSPS Management Cables
- B.11. Cabinet Power Requirements
- B.12. Troubleshooting
- C. Cable Crimping
- D. Connector Pinouts for SPR with DB9
- E. Evaluating Link Quality
- F. Technical Specifications
- G. Third-Party External Antenna Specifications
- H. Declaration of Conformity
About this Guide Hardware Installation Guide
xviii Airspan Networks Inc. 02030311-07
Appendix F, "Technical Specification": lists the technical specifications of the
ASWipLL devices.
Appendix G, "Third-Party External Antenna Specifications": lists the
technical specifications of third-party external antennas.
Appendix H, "FCC Declaration of Conformity for IDR": provides a
declaration of FCC conformity for the IDR.
Conventions
This guide uses the following bulletin conventions:
Warning: Provides information that can prevent and avoid bodily o
r
mechanical harm.
Note: Provides useful information.
Customer Service
For service and support for your ASWipLL system, contact your regional Airspan
representative, or Airspan’s Technical Assistance Center (TAC) at:
E-mail: WipLL.tech_support@Airspan.com
Boca Raton Call Center: (+1) 561 893-8679
UK Call Centre: (+44) 1895 467 467
