Specifications

Ceiling Cassette Systems
SUPER ENERGY EFFICIENCIESSUPER ENERGY EFFICIENCIES
SYSTEMS 18RCLX, 24RCLX, 36RCLX, 42RCLX
UP TO 16-SEER
Up to 16-SEER, these models provide up to 60% increase in
efficiency over 10-SEER models. These models offer the
ability to send up to 50% of their capacity through two branch
ducts to adjacent rooms. Slender fit feature now offered on all
models decreases space required above the ceiling increasing
application opportunities.
Function
Standard Features
Applications
Four-way airflow, concealed flush mount design and the
ability to operate in high ceiling rooms makes these systems
ideal for commercial applications such as offices, conference
rooms, restaurants, night clubs and bars in retrofit and new
construction. Long maximum combined piping lengths of 165
to 230 feet with 60 to 98 feet of height, depending on model,
allow the outdoor unit to be remotely located up to 7 stories
away and far from indoor unit. The ceiling cassettes are also
used in new construction condominiums and homes taking
advantage of their branch duct capability to feed adjacent
rooms. These heat pumps provide up to 30% additional
available heat when compared to conventional models.
Weekly Timer
Dry Mode
Auto Louver: Up/ Down
Auto Mode
Energy Saver
Auto Restart/Reset
Auto Changeover
Child Lock Capable
Controls Up To 16 Systems
Low Ambient
Cold Prevention
Slender Fit
Remote Controller Sensor
Pump Down Operation
High Ceiling Mode
Branch Duct Capable
Full Function Wired Remote
Slender Fit
Cassette body can
be moved downward
into the room 1-3/8”
to accommodate limited
ceiling space.
Wired Controller
• Weekly timer
• Set on-off time twice a day
• Set different on-off time by day
• Set time in 5 minute intervals
• Control up to 16 indoor units
Standard Depth
18RCLX
24RCLX
36RCLX
42RCLX
9-3/4” 11-7/8”
Slender Fit Depth
18RCLX
24RCLX
36RCLX
42RCLX
8-1/2” 10-1/2”
