Specifications

Wall Mounted 18,000 BTU Systems
ENGINEERING SOPHISTICATIONENGINEERING SOPHISTICATION
SYSTEMS 18CL, 18RL
18CL 18RL
18,000
5,500~19,000
18,000
5,500~19,000
-
-
21,600
4,600~29,000
- 10.0
19.0 19.0
10.4 10.4/11.2
14~115 (-10~46)
-
5.9 (2.8)
14~115 (-10~46)
5~75 (-15~24)
5.9 (2.8)
208-230/60/1 208-230/60/1
20 20
412 (700) 412 (700)
342 (581) 342 (581)
271 (460) 271 (460)
218 (370) 218 (370)
44 44/37 (Clg/Htg)
38 38/37 (Clg/Htg)
32 32/32 (Clg/Htg)
25 25/27 (Clg/Htg)
860 860/820
50 50/51 (Clg/Htg)
7.7/9.0 7.79.0
- 8.6/13.5
1.73/2.0 1.73/2.0
- 1.93/2.9
4 + Auto 4 + Auto
Manual Manual
Automatic Automatic
Washable Washable
No No
Flare Flare
66 (20) 66 (20)
49 (15) 49 (15)
Suc. 1/2 Dis. 1/4 Suc. 1/2 Dis. 1/4
20 (9) 88 (40) 20 (9) 88 (40)
10-13/16 22-3/4 10-13/16 22-3/4
275 578 275 578
31-1/8 31-1/8 31-1/8 31-1/8
790 790 790 790
8-7/16 11-13/16 8-7/16 11-13/16
215 300 215 300
R410A R410A
19-SEER
Indoor
ASU18CL
Outdoor
AOU18CL
Indoor
ASU18RL
Outdoor
AOU18RL
19-SEER cooling-only and heat pump systems provide almost
a 90% increase in efficiency over conventional 10-SEER
models and feature ultra compact size, R410A refrigerant,
quieter operation and increased energy efficiency. Indoor units
are over 30% smaller than competing units, making them easi-
er to install in more locations.
Function
Standard Features
Applications
Clean, aesthetic design, small but mighty indoor units are
18-24" shorter in length than competing units, helping them
blend into any room. Ideal for spaces requiring additional
capacity but are limited on space. The flexibility of the
variable speed compressor helps system adapt to shifts in
heat load by additional guests or afternoon sun. This heat
pump provides 17% additional available heat when
compared to conventional models.
Wireless Remote Control
Sleep Timer
24 Hour Timer
Dry Mode
Auto Louver: Up/ Down
Auto Mode
Quiet Mode
Optional Remote
Weekly Timer
Full Function Wired Remote
Child Lock Capable
Auto Restart/Reset
Auto Changeover
Low Ambient
Cold Prevention
Apple Catechin Filter
Ion Deodorizing Filter
Coil Dry Mode
Note: Figures are based on 230 Volts.
UTB-UUB
Nominal Cooling
BTU/h
Min.~Max. Cooling BTU/h
Nominal Heating BTU/h
Min.~Max. Heating BTU/h
HSPF BTU/hW
SEER BTU/hW
EER Clg/Htg
Clg. Operating Range °F(°C)
Htg. Operating Range °F(°C)
Moisture Removal
Pt./h(l/h)
Voltage/Frequency/Phase
Recommended Fuse Size
(A)
Air Circ. C.F.M. (m
3
/h): Hi
Medium
Low
Quiet
Noise Level
dB(A): Hi
Medium
Low
Quiet
Outdoor Fan Speed
RPMClg/Htg
Outdoor Noise Level dB(A)
Current Rated/Max (A): Cooling
Heating
Power Use
Rated/Max (kw): Cooling
Heating
Fan Speeds Stage
Air Direction: Horizontal
Vertical
Air Filter
Plasma Filter
Connection Method
Combined Max. Lgth
Ft (m)
Max. Vertical Diff. Ft (m)
Conn. Pipe Diameter Inch
Net Weight lbs. (kg)
Dimensions: Height Inch
mm
Width Inch
mm
Depth Inch
mm
Refrigerant
Cooling Only Heat Pump
