15 Appendix C: Factory Default Settings
When shipped from the factory, or following a reset to factory defaults, or operation of the hard
reset button, the instrument will be set up as follows:
(note that some parameters are relevant only if Option U01 is fitted)
Frequency/Span
(Mode = Centre/Span)
Centre = 1350.5MHz/650.5MHz
(Start = 1MHz)
Span = 2699MHz/1299MHz
(Stop = 2700MHz/1300MHz)
Fix Start/Fix Stop = Off
Freq. Presets = Empty
Step Size = 1.0000MHz
Auto Step Size = Off
Zero Span Demodulation
Setup
Demod = Off
Audio Volume = 10
Sweep/Bandwidth
RBW = Auto (1MHz)
Vid Filter = On
Sweep Control = Repeat
Trigger = Free Run, Auto Rearm
Level/Limits
Ref Level = 0dBm
Units = dBm, Graticule = Normal
Scale = Normal (10db/div)
Offset/Tables
75Ohm Compensation = Off
Fixed Offset = Off (set to -10dB)
Compensation Table = Off
Compensation File = None
Limits
Limit 1 = Off (set to -50dBm)
Limit 2 = Off (set to -60dBm)
Pattern Files = None
Limit Condition = None
Limit Action = None
Limit Offsets = 0, Step = 1dB
Traces/Markers
Trace Control
Live Trace = On
View Trace = Off
Reference Trace = Off
Ref. Trace File = None
Trace Mode
Mode = Normal
Average Number = 16
Display = Single Trace
Trace Stores
Store Type = Live Trace
Recall Type = Trace Only
Default File Names = TRACE
and IMAGE
Marker Setup
Marker 1 = On, Marker 2 = Off
M1 = 1350.5MHz /650.5MHz
Marker Units = As Graticule
Markers Function = Scroll
M1 Fix = Off
Setup/Functions
Logging
Status = Disabled
Type = Centre Level
Default File Name = LOG_
Trigger =Timer
Timer Interval = 1 sec.
Setups
Default File Name = SETUP
System/File Ops
Selected Folder = TRACES
Brightness = 40%
System Utilities
View on PC = Disabled
Auto Power Off = Never
Power-On State = Last Used
The operation to reset to Factory Defaults is described in section 4.9.1.
