FIGURE 21 (Left Hand Side View)

ENGLISH

STEP 21: (SEE FIGURE 21)

• Placethelongendofthebladepivotroddown

throughthebladepivotshaft.Attachtheshortendof

thebladepivotrodtothelifthandletube.Secureboth

endswithsmallhairpincotters.

• Usethetwoplastictiestoholdthecablesecurely

totheoutsideofthehandletubeandawayfromthe

tractortoavoiddirectheatfromthetractormuffler.

BLADE

PIVOT

ROD

LIFT HANDLE

TUBE

SMALL HAIRPIN

COTTER (N)

SMALL HAIRPIN COTTER (N)

PLASTIC TIES (DD)

BLADE PIVOT SHAFT
