3 Characteristics and Specifications
Environmental Specifications
70 U8030A Series User’s Guide
Environmental Specifications
Connection Specifications
Table 3 - 6 Environmental specifications
Parameter U8031A/U8032A
Operating temperature 0 °C to 40 °C
Storage temperature –40 °C to 70 °C
Humidity 15% RH (relative humidity) to 85% RH at 40 °C (non-condensing)
Altitude Up to 2000 meters
Fan acoustic noise • No load: follow Agilent Class CO, 45 dB sound pressure and 50 dB sound
power
• Full load: follow Agilent Class GP, 55 dB sound pressure and 60 dB sound
power
Environment of use • Installation Category II
• Pollution Degree 2
Table 3 - 7 Connection specifications
Parameter U8031A/U8032A
Output connections +Out, –Out, and chassis ground on the front panel.
(Either positive or negative output terminal may be grounded or can be operated floating at up to
a maximum of 240 V off ground. Total output voltage to ground must not exceed 240 V
DC
)
Binding posts Output binding post located horizontally and side by side
I/O connections N/A
AC input Three pins standard IEC AC power connector with fuse and line selection at
the rear
