Characteristics and Specifications 3
Physical Characteristics
U8030A Series User’s Guide 67
Physical Characteristics
Stability (output drift)
Following a 30-minute warm-up, with the output in the
ON state according to the operating mode (CC with load
or CV), and with a change in the output over 8 hours
under constant load, line, and ambient temperature.
• Voltage: <0.02%
• Current: <0.1%
Programming accuracy (23 °C ± 5 °C)
• CV: ≤0.25% + 15 mV
• CC: ≤0.30% + 15 mA
Meter readback accuracy (23 °C ± 5 °C)
• CV: ≤0.25% + 10 mV
• CC: ≤0.25% + 10 mA
Programming/Meter resolution
• Voltage: 10 mV (4 digits)
• Current: 10 mA (3 digits)
Maximum output float voltage ±240 V
DC
Table 3 - 2 Physical characteristics
Parameter U8031A/U8032A
Display LCD with amber backlight
Rotary knob for reading adjustment Yes
Size 4U, half rack
Dimensions 179.0 mm × 212.3 mm × 379.0 mm
Weight 8.2 kg
Table 3 - 1 Electrical specifications (continued)
Parameter U8031A U8032A
