3 Characteristics and Specifications
Electrical Specifications
66 U8030A Series User’s Guide
Electrical Specifications
NOTE
The specifications stated are based on a 1 hour warm-up period.
Table 3 - 1 Electrical specifications
Parameter U8031A U8032A
Total power output (W) 0 W to 375 W
Voltage output (V)
Output Channel 1 & 2
(@ 0 °C to 40 °C)
0 V to 30 V 0 V to 60 V
Current output (A)
Output Channel 1 & 2
(@ 0 °C to 40 °C)
0 A to 6 A 0 A to 3 A
Number of outputs
Three isolated output
• Two variable: CV and CC operation
• One fixed: CV operation only
5 V fixed output
[1]
Output Channel 3
• Voltage/Current output: 5 V, 3A
• Output accuracy: ≤5% or (5 V ± 0.25 V)
• V
rms
: <2 mV
rms
, or V
pp
: <50 mV
pp
• Load and line regulation: ≤5 mV
• Overload condition: 3 A + 20% (typical)
Note:
[1] The specifications referenced in this row are for Output Channel 3 (5 V fixed output). All other specifications listed in this
table are intended for Output Channel 1 and 2, unless otherwise stated.
Line and load regulation (for variable output)
• CV: <0.01% + 2 mV
• CC: <0.02% + 2 mA
Ripple and noise
Based on calculation at temperature of 18 °C to 28 °C
and bandwidth at 20 Hz to 20 MHz.
• CV: ≤1 mV
rms
, 0.5 mV
rms
(typical) or ≤10 mV
pp
, 5 mV
pp
(typical)
• CC: ≤1 mA
rms
Load transient response time
Within 15 mV from full load to half load and from half
load to full load.
<50 μs
