Output On/Off Operation
U8030A Series User’s Guide 45
Output On/Off Operation
The following steps show you how to turn on all outputs at
the same time or to turn on each output individually.
Turn on or off all outputs
When the power supply is turned on, all outputs (Output 1,
Output 2, and the 5 V output) are disabled by default.
1 Enable all outputs at the same time.
• Press the [All On/Off] button to enable all the outputs in
a single button press.
• The OFF annunciator turns off.
• The display shows voltage and current values for
Output 1 on line 1 and Output 2 on line 2.
• The 5 V annunciator turns on.
2 Disable all outputs at the same time.
• If any of the outputs are enabled, pressing the [All
On/Off] button will disable all the outputs.
NOTE
If all the outputs are disabled, pressing the [All On/Off] button will enable
all the outputs.
