User`s guide
Table Of Contents
- Agilent U8030A Series Triple Output DC Power Supply
- Table of Contents
- List of Figures
- List of Tables
- Introduction
- Operation and Features
- Constant Voltage Operation
- Constant Current Operation
- 5 V Operation
- Track Mode Operation
- Output On/Off Operation
- Memory Operations
- Memory Output Operations
- Programming the Overvoltage Protection
- Programming the Overcurrent Protection
- Keylock Operation
- System-Related Operations
- Extending the Voltage and Current Range
- Characteristics and Specifications
Introduction 1
Your Power Supply in Brief
U8030A Series User’s Guide 29
Rear panel
The rear panel parts of your power supply are described in
this section.
Figure 1-5 The rear panel at a glance
19 [POWER] Turns the power supply on or off.
20
Output 1
binding posts
Positive, negative, and ground (shared) binding
posts for Output 1 wire connections.
21
Output 2
binding posts
Positive, negative, and ground (shared) binding
posts for Output 2 wire connections.
22 5 V binding posts
Positive and negative binding posts for 5 V output
wire connections.
Table 1 - 2 Front panel legends and descriptions (continued)
Legend Description
1
2
3
4
5
