Agilent U3606A Multimeter

6
Digital multimeter specifications (continued)
Frequency specifications
Function Input range
Frequency range:
minimum input
frequency = 1 Hz
Accuracy
±(% of reading + % of range)
Temperature
coefficient
0 ºC to 18 ºC
28 ºC to 55 ºC1 year (23 ºC ± 5 ºC)
Frequency Voltage:
100 mV to 750 V
1
< 2 Hz
< 20 Hz
20 Hz to 100 kHz
100 kHz to 300 kHz
0.18 + 0.003
0.04 + 0.003
0.02 + 0.003
0.02 + 0.003
0.005
0.005
0.005
0.005
Current:
10 mA to 3 A
< 2 Hz
< 20 Hz
20 Hz to 10 kHz
0.18 + 0.003
0.04 + 0.003
0.02 + 0.003
0.005
0.005
0.005
Input range
2
Minimum frequency sensitivity for voltage measurement (RMS sine wave)
20 Hz to 100 kHz 100 kHz to 300 kHz 300 kHz to 1 MHz
100 mV
1.0 V
10 V
100 V
750 V
50 mV
100 mV
1 V
10 V
100 V
50 mV
120 mV
1.2 V
12 V
–
0.5 V
0.5 V
–
–
–
Input range
Minimum frequency sensitivity for current measurement (RMS sine wave)
20 Hz to 100 kHz
10 mA
100 mA
1 A
3 A
1 mA
10 mA
100 mA
300 mA
1. For 100 mV and 1 V ranges, the measurable frequency is up to 1 MHz at 0.5 V input signal.
2. Maximum input for the specified accuracy = 10 x range or 1000 V
dc
.
All frequency counters are susceptible to errors when measuring low-voltage, low-frequency signals. Shielding inputs from
external noise pickup is critical for minimizing measurement errors.
Duty cycle and pulse width specifications
Function Range Resolution Accuracy at full scale
Duty cycle 100.000%
1
0.001% 0.3% + 0.2% per kHz
Pulse width 199.999 ms
2
1999.99 ms
2
0.001 ms
0.01 ms
Duty cycle/frequency
Duty cycle/frequency
1. The range is from {10 µs × frequency × 100%} ~ {[1 – (10 µs × frequency)] × 100%}. For example, a 1 kHz signal can be measured from
1% ~ 99%.
2. The positive or negative pulse width must be greater than 10 µs. The range of the pulse width is determined by the frequency of the signal.
