Agilent U3606A Multimeter
4
Digital multimeter specifications
Specification assumptions:
• Specifications stated are after 60-minutes of warm-up and for 5½-digit resolution
• One-year calibration cycle, with calibration temperature of 18 °C to 20 °C
• Operating temperature: 18 °C to 28 °C (64.4 °F to 82.4 °F)
• Accuracy is expressed as ±(% of reading + % of range)
• Temperature coefficient: Add [0.1 x (the specified accuracy) / °C] for 0 °C to 18 °C and 28 °C to 55 °C
• Relative humidity (RH) up to 80% at 30 °C, proportional to 50% for 30 °C to 55 °C
DC specifications
Function Range
1
Test current
or burden
voltage
Accuracy ±(% of reading + % of range)
Temperature
coefficient
0 ºC to 18 ºC
28 ºC to 55 ºC
24 hours
2
23 ºC ± 1 ºC
90 days
23 ºC ± 5 ºC
1 year
23 ºC ± 5 ºC
DC voltage 100.000 mV
1.00000 V
10.0000 V
100.000 V
1000.00 V
–
–
–
–
–
0.012 + 0.008
0.012 + 0.005
0.012 + 0.005
0.012 + 0.005
0.012 + 0.005
0.015 + 0.008
0.015 + 0.005
0.015 + 0.005
0.015 + 0.005
0.015 + 0.005
0.025 + 0.008
0.025 + 0.005
0.025 + 0.005
0.025 + 0.005
0.025 + 0.005
0.0015 + 0.0005
0.0010 + 0.0005
0.0020 + 0.0005
0.0015 + 0.0005
0.0015 + 0.0005
DC current
3
10.0000 mA
100.000 mA
1.00000 A
3.0000 A
< 0.2 V
< 0.2 V
< 0.3 V
< 0.7 V
0.05 + 0.015
0.05 + 0.005
0.05 + 0.007
0.05 + 0.007
0.05 + 0.015
0.05 + 0.005
0.05 + 0.007
0.05 + 0.007
0.05 + 0.015
0.05 + 0.005
0.15 + 0.007
0.15 + 0.007
0.0060 + 0.0005
0.0060 + 0.0005
0.0100 + 0.0005
0.0150 + 0.0010
Resistance
4
100.000
1000.00
10.0000 k
100.000 k
1.00000 M
10.0000 M
100.000 M
0.83 mA
0.83 mA
100 A
10 A
900 nA
205 nA
205 nA || 10 M
0.04 + 0.008
0.04 + 0.005
0.04 + 0.005
0.04 + 0.005
0.05 + 0.005
0.20 + 0.005
1.60 + 0.005
0.04 + 0.008
0.04 + 0.005
0.04 + 0.005
0.04 + 0.005
0.05 + 0.005
0.20 + 0.005
1.60 + 0.005
0.05 + 0.008
0.05 + 0.005
0.05 + 0.005
0.05 + 0.005
0.06 + 0.005
0.25 + 0.005
2.00 + 0.005
0.0050 + 0.0005
0.0050 + 0.0005
0.0050 + 0.0005
0.0050 + 0.0005
0.0050 + 0.0005
0.0150 + 0.0005
0.1500 + 0.0005
Continuity 1.0000 k 0.83 mA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050 + 0.0005
Diode
5
1.0000 V 0.83 mA 0.04 + 0.005 0.04 + 0.005 0.05 + 0.005 0.0050 + 0.0005
Capacitance
6
1.000 nF
10.00 nF
100.00 nF
1.000 F
10.00 F
100.0 F
1000 F
10000 F
0.75 A
0.75 A
8.3 A
83 A
83 A
83 A
0.83 mA
0.83 mA
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
2.0 + 0.8
1.0 + 0.5
1.0 + 0.5
1.0 + 0.5
1.0 + 0.5
1.0 + 0.5
1.0 + 0.5
2.0 + 0.5
0.02 + 0.001
0.02 + 0.001
0.02 + 0.001
0.02 + 0.001
0.02 + 0.001
0.02 + 0.001
0.02 + 0.001
0.02 + 0.001
1. 20% over-range on all ranges, except for 1000 V
dc
range.
2. Relative to calibration standards.
3. Any current measurement greater than 500 mA will have a temporary thermo-effect. If you wish to measure a lower current or offset current im-
mediately after a high-current measurement, ensure that the U3606A has cooled down.
4. Specifications stated are for 2-wire resistance measurements using Null math operation. Without Null, add a 0.2 Ω error. To eliminate noise interfer-
ence which may be induced by the test leads, a shielded test cable is recommended for resistances above 100 kΩ.
5. Specifications stated are for the voltage measured at the input terminals only. The test current (1 mA) is typical. Variation in the current source will
create some variation in the voltage dropped across a diode junction.
6. Specifications stated are for open test lead measurements with film capacitor or better, using Null math operation.
