Agilent U3606A Multimeter

General characteristics

Power supply • Universal 100 V

to 240 V

±10%

• AC line frequency 45 Hz to 66 Hz (360 Hz to 440 Hz for 100/120 V operation)

Power consumption 150 VA maximum

Current Input Fuse 3.15 A, 500 V FF fuse (on front panel)

Display Highly visible vacuum-fluorescent display (VFD)

Operating environment • Operating temperature from 0 °C to +55 °C

• Relative humidity up to 80% at 30 °C RH (non-condensing)

• Altitude up to 2000 meters

• Pollution degree 2

• For indoor use only

Storage compliance –40 °C to 70 °C

Safety compliance Certified with:

• IEC 61010-1:2001/EN61010-1:2001 (2nd Edition)

• Canada: CAN/CSA-C22.2 No. 61010-1-04

• USA: ANSI/UL 61010-1:2004

EMC compliance Certified with:

• IEC61326-1:2005 / EN61326-1:2006

• CISPR 11:2003 / EN55011:2007 (Group 1 Class A)

• Canada: ICES/NMB-001:2004

• Australia/New Zealand: AS/NZS CISPR11:2004

Shock and vibration Tested to IEC/EN 60068-2

Remote interface • GPIB IEEE-488

• Full Speed USB 2.0 (Type B)

• USBTMC 488.2 Class device

• USB-CDC

Programming language Standard Commands for Programmable Instruments (SCPI)

Measurement category • CAT II, 300 V

• CAT I, 1000 V

, 750 V

rms

• 2500 V

transient over voltages

Dimensions (H × W × D) 105 × 255 × 329 mm (with rubber bumpers)

87 x 215 x 312 mm (without rubber bumpers)

Weight 3.775 kg (with rubber bumpers)

3.535 kg (without rubber bumpers)

Warranty Three years

Calibration cycle One year

Warm-up time 60 minutes
