Agilent U3606A Multimeter

10
Power supply specifications
Specification assumptions:
• Specifications stated are after 60-minutes of warm-up with no load
• Operating temperature: 18 °C to 28 °C (64.4 °F to 82.4 °F)
• Accuracy is expressed as ±(% of output + offset) at 23 °C ± 5 °C
• Temperature coefficient: Add [0.1 x (the specified accuracy) / °C] for 0 °C to 18 °C and 28 °C to 55 °C
• Relative humidity (RH) up to 80% at 30 °C, proportional to 50% for 30 °C to 55 °C
DC power supply specifications
Output ratings • Range S1: 0 V to 30 V, 0 A to 1 A
• Range S2: 0 V to 8 V, 0 A to 3 A
Programming accuracy
1 year (@ 23 ºC ± 5 ºC), ±(% of output + offset)
• 0.05% + 5 mV
• 0.15% + 3 mA
Readback accuracy
1 year over GPIB and USB or front panel with respect to
actual output (@ 23 ºC ± 5 ºC), ±(% of output + offset)
• 0.05% + 5 mV
• 0.15% + 3 mA
Ripple and noise
With outputs ungrounded, or with either output
terminal grounded, 20 Hz to 1 MHz
3
• < 2 mV
rms
; < 30 mV
pp
• < 1 mA
rms
Front terminal load regulation
±(% of output + offset)
• < 3 mV
1
• < 0.03% + 0.3 mA
Rear terminal load regulation
±(% of output + offset)
• < 0.01% + 3 mV
• < 0.03% + 0.3 mA
Line regulation Voltage: 3 mV
Current: 1.5 mA
Programming resolution 1 mV, 0.1 mA
Readback resolution 1 mV, 0.1 mA
Front panel resolution 1 mV, 0.1 mA
Transient response time Less than 450 ms for output to recover to within 50 mV following a
change in output current from full load to half load or vice versa
Command processing time Average time for output voltage to begin to change after receipt of
digital data when instrument is connected directly to the USB or GPIB
is less than 100 ms
Overvoltage protection (for CC mode) • Accuracy: 0.5% + 0.5 V
• Activation time
2
: < 2ms
Overcurrent protection (for CV mode) • Accuracy: 0.5% + 0.05 A
• Activation time
2
: < 2 ms
1. Contacts and leads resistance may contribute an additional error of 6 mV/A (typical).
2. Average time for the detection of OVP or OCP condition.
3. Refer to U3606A User’s and Service Guide (U3606-90013); CV noise effect measurement on page 166.
