4ROUTe Subsystem
18 U2751A Programmer’s Reference Guide
ROUTe:CLOSe
Syntax
ROUTe:CLOSe (@<ch_list>)
This command closes the specified channels in the channel list. The
channel number represents the matrix cross-point of a row (one digit) and
a column (two digits). For example, channel 308 represents cross-point at
row 3 and column 8.
Parameter
Examples
See Also
ROUTe:CLOSe?
ROUTe:OPEN
Item Type Range of values Default value
<ch_list> NR1 101 through 408 N/A
ROUT:CLOS (@101) // For single channel selection.
ROUT:CLOS (@201:203) // By using ‘:’ for multiple channel
selection in the same row.
NOTE
Please refer to Chapter 1, “Channel List Parameters” on page 6 for more possible
combinations of this command.
