Status Byte Register
The Status Byte summary register reports conditions from the other status
registers. The bits are not cleared when you read the register.
Bit Definitions: Status Byte Register
The Status Byte summary register will be cleared when:
• you execute the clear status (*CLS) command
• querying the Standard Event register (*ESR? command will clear only
bit 5 in the summary register)
The Status Byte Enable register is cleared when you execute the *SRE 0
command.
Bit number Decimal value Definition
0 Not Used 1 Always zero.
1 Not Used 2 Always zero.
2 Error Queue 4 There is at least one error code in the error queue. Use the
SYSTem:ERRor? command to read and clear the error from the
queue.
3 Not Used 8 Always zero.
4 Message Available 16 Data is available in the instrument's output buffer.
5 Standard Event 32 One or more bits are set in the Standard Event register (bits must be
enabled, refer to the *ESE command).
6 Master Summary 64 One or more bits are set in the Status Byte register and may
generate a Request for Service (RQS). Bits must be enabled using
the *SRE command.
7 Not Used 128 Always zero.
