User`s guide
Table Of Contents
- Agilent U1231A, U1232A, and U1233A Handheld Digital Multimeter
- Table of Contents
- List of Figures
- List of Tables
- Introduction
- Making Measurements
- Multimeter Features
- Multimeter Setup Options
- Using the Setup Menu
- Setup Menu Summary
- Setup Menu Items
- Changing the variation count
- Enabling and changing the Smooth refresh rate
- Enabling and changing the voltage alert level
- Changing the beep frequency
- Changing the auto power-off (APO) timeout
- Changing the LCD backlight timeout
- Adjusting the LCD backlight intensity
- Enabling the LED flashlight timeout
- Adjusting the LED flashlight intensity
- Changing the minimum measurable frequency
- Changing the continuity test alerts
- Changing the power-on greeting tone
- Resetting the Setup items
- Changing the scale conversion value
- Enable the AC/DC mV measurement
- Enable open continuity test by default
- Changing the temperature unit
- Characteristics and Specifications
VI U1231A/U1232A/U1233A User’s Guide
Environmental Conditions
This instrument is designed for indoor use and in an area with low
condensation. The table below shows the general environmental
requirements for this instrument.
Environmental condition Requirement
Operating temperature Full accuracy from –10 °C to 55 °C
Operating humidity
Full accuracy up to 80% RH (relative
humidity) for temperature up to 30 °C,
decreasing linearly to 50% RH at 55 °C
Storage temperature –40 °C to 60 °C
Altitude Up to 2000 meters
Pollution degree 2
NOTE
The U1231A/U1232A/U1233A Handheld Digital Multimeter complies with the
following safety and EMC requirements:
• IEC 61010-1:2010/EN 61010-1:2010
• USA: UL 61010-1 (3rd Edition)
• Canada: CSA C22.2 No. 61010-1:2012
