1 Introduction
Your Multimeter in Brief
26 U1231A/U1232A/U1233A User’s Guide
Measurement units
The available signs and notations for each measurement
function in your multimeter are described in Table 1- 8. The
units listed below are applicable to the primary display
measurements of your multimeter.
Battery capacity indication page 5
Overload (the reading exceeds the display
range)
-
Table 1 - 8 Measurement units display
Sign/Notation Description
M Mega 1E+06 (1000000)
k kilo 1E+03 (1000)
n nano 1E–09 (0.000000001)
μ micro 1E–06 (0.000001)
m milli 1E–03 (0.001)
mV, V Voltage units for voltage measurement
A, μA Ampere units for current measurement
nF, μF, mF Farad units for capacitance measurement
Ω, kΩ, MΩ Ohm units for resistance measurement
MHz, kHz, Hz Hertz units for frequency measurement
°C Degree Celsius, unit for temperature measurement
°F Degree Fahrenheit, unit for temperature measurement
Table 1 - 7 General annunciators (continued)
Legend Description Learn more on:
