Programming Examples
Using the Programming Examples
Chapter 2 33
Programming Examples Development Environment
The C/C++ examples in this guide were written using an IBM-compatible personal computer
(PC) with the following configuration:
•Pentium
®
processor
• Windows NT 4.0 operating system
• C/C++ programming language with the Microsoft Visual C++ 6.0 IDE
• National Instruments PCI- GPIB interface card or Agilent GPIB interface card
• National Instruments VISA Library or Agilent VISA library
• COM1 or COM2 serial port available
• LAN interface card
The Agilent BASIC examples were run on a UNIX 700 Series workstation
Running C/C++ Programming Examples
To run the example programs written in C/C++ you must include the required files in the
Microsoft Visual C++ 6.0 project.
If you are using the VISA library do the following:
• add the visa32.lib file to the Resource Files
• add the visa.h file to the Header Files
If you are using the NI-488.2 library do the following:
• add the GPIB-32.OBJ file to the Resource Files
• add the windows.h file to the Header Files
• add the Deci-32.h file to the Header Files
Refer to the National Instrument website for information on the NI-488.2 library and file
requirements. For information on the VISA library see the Agilent website or National
Instrument’s website.
Pentium is a U.S. registered trademark of Intel Corporation
