Command Reference
SCPI Command Compatibility
Chapter 4334
Pulse Subsystem
[:SOURce]:PULSe:DELay delay|MINimum|MAXimum|UP|DOWN|
DEFault
Y
[:SOURce]:PULSe:DELay?
Y
[:SOURce]:PULSe:DELay:STEP <num>[<time suffix>][DEFault]
Y
[:SOURce]:PULSe:DELay:STEP? [DEFault]
Y
[:SOURce]:PULSe:DOUBle[:STATE] ON|OFF
N
[:SOURce]:PULSe:DOUBle[:STATE]?
N
[:SOURce]:PULSe:FREQuency freq|MINimum|MAXimum|UP|DOWN|
DEFault
Y
[:SOURce]:PULSe:FREQuency?
Y
[:SOURce]:PULSe:FREQuency:STEP freq|DEFault
Y
[:SOURce]:PULSe:FREQuency:STEP? [MIN|MAX|DEF]
Y
[:SOURce]:PULSe:PERiod <num>[<time suffix>]|UP|DOWN
Y
[:SOURce]:PULSe:PERiod?
Y
[:SOURce]:PULSe:PERiod:STEP <num>[<time suffix>]
Y
[:SOURce]:PULSe:PERiod:STEP?
Y
[:SOURce]:PULse:TRANSition[:LEADing] SLOW|MEDium|FAST
N
[:SOURce]:PULSe:TRANsition[:LEADing]?
N
[:SOURce]:PULSe:TRANsition:STATe ON|OFF
N
[:SOURce]:PULSe:TRANsition:STATe?
N
[:SOURce]:PULSe:WIDTh MAXimum|MINimum|UP|DOWN|DEFault
Y
[:SOURce]:PULSe:WIDTh? [MAXimum|MINimum|DEFault]
Y
Table 4-11 8373xB and 8371xB SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83731B
&
83732B
83711B
&
83712B
