Command Reference
SCPI Command Compatibility
Chapter 4332
[:SOURce]:MODulation:STATe?
Y
Output Subsystem
:OUTPut:IMPedance?
NN
:OUTPut:PROTection[:STATe] ON|OFF
NN
:OUTPut:PROTection[:STATe]?
NN
:OUTPut[:STATe] ON|OFF|1|0
YY
:OUTPut[:STATe]?
YY
Phase Modulation Subsystem
[:SOURce]:PM:COUPling AC|DC
Y
[:SOURce]:PM[:DEViation] <val><unit>
Y
[:SOURce]:PM[:DEViation]:STEP[:INCRement]
Y
[:SOURce]:PM:INTernal:FREQuency <val><unit>
Y
[:SOURce]:PM:INTernal:FREQuency:STEP[:INCRement]
Y
[:SOURce]:PM:INTernal:FUNCtion SINusoid|SQUare|TRIAngle|
RAMP|UNIForm|GAUSsian
Y
[:SOURce]:PM:RANGe AUTO|LOW|HIGH
Y
[:SOURce]:PM:SENSitivity sens|MINimum|MAXimum|DEFault
N
[:SOURce]:PM:SOURce FEED
[:SOURce]:PM:SOURce INTernal|EXTernal
N
Y
[:SOURce]:PM:STATe ON|OFF|1|0
Y
Power Subsystem
[:SOURce]:POWer:ALC:PMETer pmeter|MINimum|MAXimum|DEFault
NN
[:SOURce]:POWer:ALC:PMETer?
NN
Table 4-11 8373xB and 8371xB SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83731B
&
83732B
83711B
&
83712B
