Command Reference
SCPI Command Compatibility
Chapter 4 329
[:SOURce]:AM:INTernal:FUNCtion SINusoid|SQUare|TRIangle|
RAMP|NOISe|UNIForm|GAUSsian
Y
[:SOURce]:AM:SENSitivity <val>|MIN|MAX|DEF
N
[:SOURce]:AM:SOURce FEED
[:SOURce]:AM:SOURce INTernal|EXTernal
N
Y
[:SOURce]:AM:SOURce?
Y
[:SOURce]:AM:STATe ON|OFF
Y
[:SOURce]:AM:STATe?
Y
[:SOURce]:AM:TYPE LINear|EXPonential
Y
[:SOURce]:AM:TYPE?
Y
Display Subsystem
:DISPlay[:WINDow][:STATe] ON|OFF|1|0
YY
:DISPlay[:WINDow][:STATe]?
YY
Initiate Subsystem
:INITiate:CONTinuous ON|OFF|1|0
Y
:INITiate:CONTinuous?
Y
Correction Subsystem
[:SOURce]:CORRection:FLATness[:DATA] <freq>,<corr.>,...
<freq>,<corr.>
YY
[:SOURce]:CORRection:FLATness:POINts <points>
YY
[:SOURce]:CORRection[:STATe] ON|OFF
YY
[:SOURce]:CORRection[:STATe]?
YY
[:SOURce]:CORRection:CSET[:SELect] tableno
NN
Table 4-11 8373xB and 8371xB SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83731B
&
83732B
83711B
&
83712B
