Command Reference
SCPI Command Compatibility
Chapter 4328
*PMC
NN
*PSC
YY
*PSC?
YY
*RCL <reg_num>
YY
*RMC
NN
*RST
YY
*SAV <reg_num>
YY
*SRE <data>
YY
*SRE?
YY
*STB?
YY
*TST?
YY
*WAI
YY
Abort Subsystem
:ABORt
Y
Amplitude Modulation Subsystem
[:SOURce]:AM[:DEPTh] <val><unit>
Y
[:SOURce]:AM[:DEPTh] <num>[<PCT>]|<num>DB
Y
[:SOURce]:AM[:DEPTh]:STEP[:INCRement] incr|MINimum|
MAXimum|DEFault
Y
[:SOURce]:AM:INTernal:FREQuency <num>[<freq suffix>] incr|
MINimum|MAXimum|DEFault
Y
[:SOURce]:AM:INTernal:FREQuency:STEP[:INCRement]
Y
Table 4-11 8373xB and 8371xB SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83731B
&
83732B
83711B
&
83712B
