Command Reference
SCPI Command Compatibility
Chapter 4 327
8373xB and 8371xB Compatible SCPI Commands
Table 4-11 is a comprehensive list of 8373xB and 8371xB SCPI commands arranged by
subsystem. Commands that are supported by the PSG Family are identified, in addition to
commands that are unsupported. Use the legend within the table to determine command
compatibility.
Some of the PSG supported commands are subsets of the 8373xB and 8371xB commands.
When this occurs, the syntax supported by the PSG Family is shown in addition to the syntax
that is not supported.
Table 4-11 8373xB and 8371xB SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83731B
&
83732B
83711B
&
83712B
IEEE Common Commands
*CLS
YY
*DMC
NN
*EMC
NN
*EMC?
NN
*ESE <data>
YY
*ESE?
YY
*ESR?
YY
*GMC?
NN
*IDN?
a
YY
*LMC?
NN
*LRN?
NN
*OPC
YY
*OPC?
YY
*OPT?
NN
