Command Reference
SCPI Command Compatibility
Chapter 4 325
:SYSTem:MMHead:SELect FRONt|REAR|NONE
c
YY
:SYSTem:MMHead:SELect?
YY
:SYSTem:PRESet[:EXECute]
YY
:SYSTem:PRESet:SAVE
YY
:SYSTem:PRESet:TYPE FACTory|USER
YY
:SYSTem:PRESet:TYPE?
YY
:SYSTem:SECurity:COUNt <value>
de
YY
:SYSTem:SECurity:COUNt? [MINimum|MAXimum]
YY
:SYSTem:SECurity[:STATe] ON|OFF|1|0
e
YY
:SYSTem:SECurity[:STATe]?
YY
:SYSTem:VERSion?
YY
Trigger Subsystem
:TRIGger[:IMMediate]
YY
:TRIGger:ODELay <value>[time suffix]|MAXimum|MINimum
NN
:TRIGger:ODELay? [MAXimum|MINimum]
NN
:TRIGger:SOURce IMMediate|BUS|EXTernal
YY
:TRIGger:SOURce?
YY
Tsweep Subsystem
:TSWeep
NN
Unit Subsystem
:UNIT:AM DB|PCT
N
:UNIT:AM?
N
Table 4-10 836xxB/L SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83620B
&
83640B
83620L
&
83640L
