Command Reference
SCPI Command Compatibility
Chapter 4322
Reference Oscillator Subsystem
:ROSCillator:SOURce?
YY
:ROSCillator:SOURce:AUTO ON|OFF|1|0
YY
:ROSCillator:SOURce:AUTO?
YY
:ROSCillator:SOURce INTernal|EXTernal|NONE
YY
Status Subsystem
:STATus:OPERation:CONDition?
YY
:STATus:OPERation:ENABle <value>
YY
:STATus:OPERation:ENABle?
YY
:STATus:OPERation[:EVENt]?
YY
:STATus:OPERation:NTRansition <value>
YY
:STATus:OPERation:NTRansition?
YY
:STATus:OPERation:PTRansition <value>
YY
:STATus:OPERation:PTRansition?
YY
:STATus:PRESet
YY
:STATus:QUEStionable:CONDition?
YY
:STATus:QUEStionable:ENABle <value>
YY
:STATus:QUEStionable:ENABle?
YY
:STATus:QUEStionable[:EVENt]?
YY
:STATus:QUEStionable:NTRansition <value>
YY
:STATus:QUEStionable:NTRansition?
YY
:STATus:QUEStionable:PTRansition <value>
YY
Table 4-10 836xxB/L SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83620B
&
83640B
83620L
&
83640L
