Command Reference
SCPI Command Compatibility
Chapter 4316
:FREQuency:STOP <num>[<freq suffix>]|MAXimum|MINimum|UP|
DOWN
YY
:FREQuency:STOP? [MAXimum|MINimum]
YY
Initiate Subsystem
:INITiate:CONTinuous ON|OFF|1|0
YY
:INITiate:CONTinuous?
YY
:INITiate[:IMMediate]
YY
List Subsystem
:LIST:DWELl {<num>[<time suffix>]|MAXimum|MINimum}
YY
:LIST:DWELl? [MAXimum|MINimum]
YY
:LIST:DWELl:POINts? [MAXimum|MINimum]
YY
:LIST:FREQuency {<value>[<freq suffix>]|MAXimum|MINimum}
YY
:LIST:FREQuency?
YY
:LIST:FREQuency:POINts? [MAXimum|MINimum]
YY
:LIST:MANual <num>
YY
:LIST:MANual?
YY
:LIST:MODE AUTO|MANual
YY
:LIST:MODE?
YY
:LIST[:POWer]:CORRection {<value>[DB]|MAXimum|MINimum}
NN
:LIST[:POWer]:CORRection?
NN
:LIST[:POWer]:CORRection:POINts? [MAXimum|MINimum]
NN
:LIST:TRIGger:SOURce IMMediate|BUS|EXTernal
YY
Table 4-10 836xxB/L SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83620B
&
83640B
83620L
&
83640L
