Command Reference
SCPI Command Compatibility
Chapter 4314
:FM:INTernal:FREQuency <num>[<freq suffix>]|MAXimum|
MINimum
Y
:FM:INTernal:FREQuency? [MAXimum|MINimum]
Y
:FM:INTernal:FUNCtion SINusoid|SQUare|TRIangle|RAMP|NOISe
Y
:FM:INTernal:FUNCtion?
Y
:FM:SOURce INTernal|EXTernal
Y
:FM:SOURce?
Y
:FM:SENSitivity <val><freq suffix/V>|MAXimum|MINimum
Y
:FM:SENSitivity? [MAXimum|MINimum]
Y
:FM:STATe ON|OFF|1|0
Y
:FM:STATe?
Y
Frequency Subsystem
:FREQuency:CENTer <num>[<freq suffix>]|MAXimum|MINimum|
UP|DOWN
YY
:FREQuency:CENTer? [MAXimum|MINimum]
YY
:FREQuency[:CW|:FIXed] <num>[<freq suffix>]|MAXimum|
MINimum|UP|DOWN
YY
:FREQuency[:CW]? [MAXimum|MINimum]
YY
:FREQuency[:FIXed]? [MAXimum|MINimum]
YY
:FREQuency[:CW]:AUTO ON|OFF|1|0
NN
:FREQuency[:CW]:AUTO?
NN
:FREQuency[:FIXed]:AUTO ON|OFF|1|0
NN
:FREQuency[:FIXed]:AUTO?
NN
Table 4-10 836xxB/L SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83620B
&
83640B
83620L
&
83640L
