Command Reference
SCPI Command Compatibility
Chapter 4 311
Calibration Subsystem
:CALibration:AM:AUTO ON|OFF|1|0
N
:CALibration:AM:AUTO?
N
:CALibration:AM[:EXECute]
N
:CALibration:PEAKing:AUTO ON|OFF|1|0
NN
:CALibration:PEAKing:AUTO?
NN
:CALibration:PEAKing[:EXECute]
NN
:CALibration:PMETer:DETector:INITiate? IDETector|DIODe
NN
:CALibration:PMETer:DETector:NEXT? <num>[<lvl suffix>]
NN
:CALibration:PMETer:FLATness:INITiate? USER|DIODe|PMETER|
MMHead
NN
:CALibration:PMETer:FLATness:NEXT? <value>[<lvl suffix>]
NN
:CALibration:SPAN:AUTO ON|OFF|1|0
NN
:CALibration:SPAN:AUTO?
NN
:CALibration:SPAN[:EXECute]
NN
:CALibration:TRACk
NN
Correction Subsystem
:CORRection:ARRay[i]{<value>[DB]}
NN
:CORRection:ARRay[i]?
NN
:CORRection:FLATness {<num>[freq suffix],<num>[DB]}2*801
NN
:CORRection:FLATness?
YY
:CORRection:SOURce[i] ARRay|FLATness
NN
:CORRection:SOURce[i]?
NN
Table 4-10 836xxB/L SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83620B
&
83640B
83620L
&
83640L
