Command Reference
SCPI Command Compatibility
Chapter 4 309
836xxB/L Compatible SCPI Commands
Table 4-10 is a comprehensive list of 836xxB/L SCPI commands arranged by subsystem.
Commands that are supported by the PSG Family are identified, in addition to commands
that are unsupported. Use the legend within the table to determine command compatibility.
Some of the PSG supported commands are a subset of the 836xxB/L commands. When this
occurs, the syntax supported by the PSG is shown in addition to the syntax that is not
supported.
Table 4-10 836xxB/L SCPI Commands
Y= Supported by PSG Family
N= Not supported by PSG Family
83620B
&
83640B
83620L
&
83640L
IEEE Common Commands
*CLS
YY
*ESE <data>
YY
*ESE?
YY
*ESR?
YY
*IDN?
a
YY
*LRN?
NN
*OPC
YY
*OPC?
YY
*OPT?
NN
*RCL <reg_num>
YY
*RST
YY
*SAV <reg_num>
YY
*SRE <data>
YY
*SRE?
YY
