Programming instructions

Command Reference
SCPI Command Compatibility
Chapter 4 303
SHKZ Write to IO not supported
SHHZ Read from IO not supported
SL0 Power slope off POWer:SLOPe:STATe OFF|0
SL1 Power slope on POWer:SLOPe:STATe ON|1
POWer:SLOPe <value>[DB/freqsuffix]
SM Sweep, manual not supported
SN Steps, maximum SWEep:POINts <val>
SP Set power step size POWer[:LEVel][:Immediate][:AMPLitude]:STEP[:
INCREment] <val>
ST Sweep time not supported
SV Save instrument state *SAV <reg_num>[,<seq_num>]
SW Swap NA channels not supported
T1 Trigger, free run not supported
T1 b Test GPIB not supported
T2 Trigger, line not supported
T3 Trigger, external not supported
TL Time line not supported
TS Take sweep not supported
UP Up step see Table 4-6 on page 304
a. PSG family uses external detector coupling factor instead of reference voltage.
b. PSG family uses AM2 path and EXT 1 input.
c. Same as DU0 on page 297 for PSG family.
d. PSG family uses FM2 path and EXT 2 input.
e. 8340B/41B: sensitivity values
≤
1 MHz are set to 1 MHz;
sensitivity values >1 MHz are set to 10 MHz
PSG Family: sensitivity is set to specified value.
f. Refer to the “:SYSTem:IDN” command on page 294 to customize the string returned by *IDN? or OI
.
g. RB command emulates knob motion on PSG family.
h. Saved under seq_num = 0, and note that RC 0 (recall last front panel settings) is not supported.
i. Same as DU1 on page 297 for PSG family.
j. Same as AT on page 296 for PSG family.
Table 4-5 8340B/41B Programming Codes and Equivalent SCPI Sequences
Code Description Equivalent SCPI Command Sequence
