Command Reference
SCPI Command Compatibility
Chapter 4 299
M2 Marker 2 on not supported
M3 Marker 3 on not supported
M4 Marker 4 on not supported
M5 Marker 5 on not supported
MC Marker to CF not supported
MD Marker delta not supported
MO Marker off not supported
MP Marker sweep M1-M2 not supported
MS msec terminator not supported
MZ MHz terminator MHZ
NA Configure for network analyzer not supported
OA Output active parameter see Table 4-6 on page 304
OB Output next band frequency not supported
OC Output coupled parameters not supported
OD Output diagnostic values not supported
OF Output fault values supported, but no equivalent SCPI command sequence
OI
f
Output identification *IDN?
OK Output last lock frequency not supported
OL Output learn data not supported
OM Output mode data not supported
OPAT Output attenuator supported, but no equivalent SCPI command sequence
OPCF Output center frequency supported, but no equivalent SCPI command sequence
OPCW Output CW frequency FREQuency[:CW]?
OPDF Output delta frequency supported, but no equivalent SCPI command sequence
Table 4-5 8340B/41B Programming Codes and Equivalent SCPI Sequences
Code Description Equivalent SCPI Command Sequence
