Command Reference
SCPI Command Compatibility
Chapter 4296
Table 4-5 8340B/41B Programming Codes and Equivalent SCPI Sequences
Code Description Equivalent SCPI Command Sequence
A1
Leveling, internal POWer:ALC:SOURce INTernal
A2
a
Leveling, external diode detector POWer:ALC:SOURce DIODe
POWer:ALC:SOURce:EXTernal:COUPling <val>DB
A3 Leveling, power meter not supported
AK Amplitude marker not supported
AL Alternate state not supported
AM0 Amplitude modulation off AM1:State OFF|0
AM2:State OFF|0
AM1
b
Amplitude modulation on AM1:State OFF|0
AM2:SOURce EXT[1]
AM2:EXTernal[1]:COUPling DC
AM2:Depth 100
AM2:EXTernal[1]:IMPedance 600
AM2:State ON|1
AS Select alternate state not supported
AT Set attenuator POWer:ATTenuation <val><unit>
AU Auto not supported
BC Change frequency band not supported
CF Center frequency (step sweep) FREQuency:MODE LIST
POWer:MODE FIXED
LIST:TYPE STEP
INITiate:CONTinuous[:ALL] ON|1
LIST:TRIGger:SOURce BUS
FREQuency:STARt <val><unit>
FREQuency:STOP <val><unit>
CS Clear both status bytes *CLS
CW Set CW frequency FREQuency:MODE CW
FREQuency[:CW] <val><unit>
DB dB(m) terminator DB
