Command Reference
List/Sweep subsystem ([:SOURce])
Chapter 4262
:SWEep:DWELl
Supported All
[:SOURce]:SWEep:DWELl <val>
[:SOURce]:SWEep:DWELl?
This command enables you to set the dwell time for a step sweep.
The variable <val> is measured in units of seconds with a 0.001 resolution.
NOTE The dwell time (<val>) does not begin until the signal generator has
settled for the current frequency and/or amplitude change. When the
signal generator has settled, a trigger signal is transmitted through the
rear panel SOURCE SETTLED OUTPUT connector.
*RST
+
2.00000000E
−
003
Range 0.001
−
60
Key Entry
Step Dwell
Remarks Dwell time is used when the trigger source is set to IMMediate. Refer
to “:LIST:TRIGger:SOURce” on page 259 for the trigger setting.
The dwell time is the amount of time the sweep is guaranteed to pause
after setting the frequency and/or power for the current point.
:SWEep:POINts
Supported All
[:SOURce]:SWEep:POINts <val>
[:SOURce]:SWEep:POINts?
This command enables you to define the number of points in a step sweep.
*RST 2
Range 2
−
1601
Key Entry
# Points
Remarks N/A
