Command Reference
Correction Subsystem ([:SOURce]:CORRection)
Chapter 4 235
:FLATness:PRESet
Supported All
CAUTION The current correction data will be overwritten once this command is
executed. Save the current data if needed. Refer to “:FLATness:STORe”
for storing user flatness files.
[:SOURce]:CORRection:FLATness:PRESet
This command presets the user flatness correction to a factory-defined setting that
consists of one point.
*RST N/A
Range N/A
Key Entry
Preset List
Remarks N/A
:FLATness:STORe
Supported All
[:SOURce]:CORRection:FLATness:STORe "<file name>"
This command stores the current user flatness correction data to a file.
*RST N/A
Range N/A
Key Entry
Store To File
Remarks N/A
