Command Reference
System Subsystem (:SYSTem)
Chapter 4210
:PON:TYPE
Supported All
:SYSTem:PON:TYPE PRESet|LAST
:SYSTem:PON:TYPE?
This command sets the defined conditions for the signal generator at power on.
PRESet This choice sets the conditions to factory- or user-defined as determined by
the choice for the preset type. Refer to “:PRESet:TYPE” on page 212 for
selecting the type of preset.
LAST This choice retains the settings at the time the signal generator was last
powered down.
NOTE When LAST is selected, no signal generator interaction can occur for at
least 3 seconds prior to cycling the power for the current settings to be
saved.
*RST N/A
Key Entry
Power On Last Preset
Remarks The setting enabled by this command is not affected by signal
generator power-on, preset, or *RST.
:PRESet
Supported All
SYSTem:PRESet
This command returns the signal generator to a set of defined conditions. It is equivalent
to pressing the front panel
Preset hardkey.
*RST N/A
Range N/A
Key Entry
Preset
Remarks The defined conditions are either factory- or user-defined. Refer to
“:PRESet:TYPE” on page 212 for selecting the type of defined
conditions.
Choices PRESet LAST
