Command Reference
Status Subsystem (:STATus)
Chapter 4206
:QUEStionable:POWer[:EVENt]
Supported All
CAUTION This is a destructive read. The data in the register is latched until it is
queried. Once queried, the data is cleared.
:STATus:QUEStionable:POWer[:EVENt]?
This command returns the decimal sum of the bits in the Data Questionable Power
Event Register. For example, if the RF output signal is unleveled (bit 1), a value of 2 is
returned.
*RST N/A
Range 0–32767
Key Entry N/A
Remarks Refer to “Data Questionable Power Status Group” on page 124 and
“Data Questionable Power Event Register” on page 126 for more
information.
The equivalent PTR or NTR filters must be set before the condition
register can set the corresponding bit in the event register.
