Programming instructions

Command Reference
Status Subsystem (:STATus)
Chapter 4192
:OPERation[:EVENt]
Supported All
CAUTION This is a destructive read. The data in the register is latched until it is
queried. Once queried, the data is cleared.
:STATus:OPERation[:EVENt]?
This command returns the decimal sum of the bits in the Standard Operation Event
Register. For example, if a sweep is in progress (bit 3), the value 8 is returned.
*RST N/A
Range 0–32767
Key Entry N/A
Remarks Refer to “Standard Operation Status Group” on page 117 and
“Standard Operation Event Register” on page 119 for more
information.
The equivalent PTR or NTR filters must be set before the condition
register can set the corresponding bit in the event register.
:PRESet
Supported All
:STATus:PRESet
This command presets all transition filters, enable registers, and error/event queue
enable registers.
*RST N/A
Range N/A
Key Entry N/A
Remarks Refer to Table 3-2 on page 109 for the status preset register values and
types.
