Programming instructions

Command Reference
Output Subsystem(:OUTPut)
Chapter 4 189
Output Subsystem(:OUTPut)
:MODulation[:STATe]
Supported PSG-A Series
:OUTPut:MODulation[:STATe] ON|OFF|1|0
:OUTPut:MODulation[:STATe]?
This command enables or disables the modulation of the RF output with the currently
active modulation type(s).
*RST 1
Key Entry
Mod On/Off
Remarks Most modulation types can be simultaneously enabled except FM with
Φ
M.
An annunciator on the signal generator is always displayed to indicate
whether modulation is switched on or off.
[:STATe]
Supported All
:OUTPut[:STATe] ON|OFF|1|0
:OUTPut[:STATe]?
This command enables or disables the RF output.
*RST 0
Key Entry
RF On/Off
Remarks Although you can configure and engage various modulations, no signal
is available at the RF OUTPUT connector until this command is
executed.
An annunciator is always displayed on the signal generator to indicate
whether the RF output is switched on or off.
Choices ON OFF 1 0
Choices ON OFF 1 0
